Enclosure Color
Black
-
Touch Technology & Capacity
PCAP (TouchPro® Projected Capacitive) – 10 Touch
-
Processor
Celeron Models: Intel® Celeron® Processor J4105 (4M Cache, up to 2.5 GHz)
i3 Models: Intel® Core™ i3-8100T Processor (6M Smart Cache, 3.10 GHz)
i5 Models: Intel® Core™ i5-8500T Processor (9M Smart Cache, up to 3.50 GHz by Intel® Turbo Boost Technology 2.0) Intel® vPro Support
-
Chipset
Celeron Models: N/A
i3 Models: Intel H310 Express
i5 Models: Intel Q370 Express
-
Graphics
Celeron Models: Intel UHD Graphics 600
i3 & i5 Models: Intel UHD Graphics 630
-
BIOS
AMI
-
Memory (RAM)
Celeron Models: 4GB 2400MHz DDR4 SO-DIMM on 1 of 2 slots (expandable to 8GB)
i3 Models: 4GB 2400MHz DDR4 SO-DIMM on 1 of 2 slots (expandable to 32GB)
i5 Models: 8GB 2400MHz DDR4 SO-DIMM on 1 of 2 slots (expandable to 32GB)
NOTE: Check brand of the memory included in your unit before purchasing the memory kit.
-
Storage
128GB M.2 SATA SSD, 72 TBW
Optional M.2 PCIe (NVMe) SSD for select models
NOTE: GB equals one billion bytes when referring to storage capacity. Accessible capacity may be less.
-
TPM
2.0
-
Active Management Technology (AMT)
Celeron Models: N/A
i3 Models: N/A
i5 Models: Active Management Technology (Intel® AMT 11.0) Support
-
Diagonal Size
21.5” diagonal, Active matrix TFT LCD (LED)
-
Aspect Ratio
16:9
-
Active Area (mm)
18.74″ x 10.54″ / 476.1 mm x 267.8 mm
-
Resolution
1920 x 1080 @ 60Hz
-
Number of Colors
16.7 million
-
Brightness (typical)
LCD Panel: 250 nits
PCAP: 212.5 nits
-
Response Time-total (typical)
14 msec
-
Contrast Ratio
1000:1
-
Viewing Angle
Horizontal: ±89° or 178° total
Vertical: ±89° or 178° total
-
USB Ports
3 x USB 3.0 (1 on display head, 2 on I/O)
2 x USB 2.0 (on I/O)
4 x Micro USB 2.0 (on display head)
-
Powered USB
1 x 24V on I/O
2 x 12V on I/O
-
Ethernet Port
1 x LAN RJ45 (Gigabit)
-
Serial Ports
2 x RJ45
-
Cash Drawer Port
12V/24V Cash Drawer Port on I/O (EPSON Pinout, 24V default; selectable by internal switch)
-
Wireless
Wi-Fi 802.11 a/b/g/n/ac 2.4GHz and 5GHz
-
Bluetooth
Bluetooth 5.0
-
Additional Video Out
1 x Full-function USB-C (Power up to 27W, USB 3.0, Display Port)
-
Audio Ports
1 x 3.5 mm headset jack
-
Speakers
2 x 2W internal speakers
-
OS
No OS
Windows 10 IoT Enterprise LTSC 64-bit
Optional – Windows 10 Professional English 64-bit
-
Languages
Windows 10 – 36 Language groups
-
Power Supply
External 24VDC universal-type power supply brick
AC input voltage: 100-240 VAC
Input frequency: 50-60 Hz
Maximum output power: 180W
-
Power Consumption (Typical)
Celeron: 31 W
i3: 72 W
i5: 81 W
-
Dimensions
With Stand: 16.4″ x 20.7″ x 10.15″ / 416.4 mm x 525.9 mm x 257.8 mm
Without Stand: 16.4″ x 20.7″ x 3.33″ / 416.4 mm x 525.9 mm x 84.7 mm
-
Shipping Box Dimensions
With Stand: 25.35″ x 14.76″ x 21.57″ / 644 mm x 375 mm x 548 mm
Without Stand: 25.35″ x 8.9″ x 17.72″ / 644 mm x 226 mm x 450 mm
-
Weight (Unpackaged)
With Stand: 19.6 lbs / 8.9 kg
Without Stand: 13.2 lbs / 6 kg
-
Weight (Packaged)
With Stand: 26.2 lbs / 11.9 kg
Without Stand: 18.5 lbs / 8.4 kg
-
Operating Temperature
0°C to 35°C / 32°F to 95°F
-
Storage Temperature
-20°C to 60°C / -4°F to 140°F
-
Humidity
Operating: 20% to 80%
Storage: 5% to 95% (38.7℃ max wet bulb temperature)
-
Energy Star
Energy Star 7.1
-
Regulatory approvals and declarations
UL/cUL, FCC, TUV, CE, CB, Mexico NOM, C-Tick/RCM, VCCI, Argentina S-Mark, CCC
-
Real-Time Clock
CR2032 lithium metal battery
-
MTBF
50,000 hours demonstrated
-
Mounting Options
75mm or 100mm VESA mount
-
Sealability
Touchscreen sealed to sub-bezel
Touchscreen sealed to LCD
-
Power Cables
North American and European power cables included
-
Other Features
Serviceable internal components
Models with a stand for desktop application
Models without a stand for 75mm VESA mounting
Kensington lock
-
What’s in the Box
EloPOS System
North America Power Cord
EU Power Cord
Power Adapter – 180W
Cable RJ-45 to DB-9
Cable cover locking screw
Quick Installation Guide (QIG)
-
Upgrade Options
4GB 2666 MHz DDR4 Memory SO-DIMM – Elo P/N: E264186
8GB 2666 MHz DDR4 Memory SO-DIMM – Elo P/N: E264375
16GB 2666 MHz DDR4 Memory SO-DIMM – Elo P/N: E263989
M.2 SATA 128GB SSD – Elo P/N: E206352
M.2 SATA 256GB SSD – Elo P/N: E206556
-
Optional Peripherals
Magnetic Stripe Reader (MSR) – Elo P/N: E001002
Fingerprint Reader (FPR) – Elo P/N: E001001
Customer Display (2×20 VFD) – Elo P/N: E001003
10″ LCD Customer-facing Display (10 touch) – Elo P/N E045337 (requires display mount kit E835969)
10″ LCD Customer-facing Display (no touch) – Elo P/N E138394 (requires display mount kit E835969)
1302L Customer-facing Display (10 touch) – Elo P/N: E683595 (requires display mount kit E835969 which includes authorized Elo 2ft USB-C cable)
2D Barcode Scanner – Elo P/N: E926356
EMV Cradle for MagTek eDynamo – Elo P/N: E375343
EMV Cradle for Ingenico RP457c (with Audio Jack, BT and USB) – Elo P/N: E586981
EMV Cradle for Ingenico RP457c (with BT and USB) – Elo P/N: E710930
Status Light (Micro-USB Connectivity) – Elo P/N: E466847
6ft Elo authorized USB-C cable – Elo P/N: E710364
-
Stands, Mounts & Kits
Shelf Mount Bracket (75mm or 100mm VESA) – Elo P/N: E043382
Floor Stand (75mm or 100mm VESA) – Elo P/N: E048069
Pole Mount – 6 inch (75mm or 100mm VESA) – Elo P/N: E047458
Pole Mount – 12 inch (75mm or 100mm VESA) – Elo P/N: E047663
Pole Mount – 18 inch (75mm or 100mm VESA) – Elo P/N: E047864
Pole Mount Bracket (75mm or 100mm VESA) – Elo P/N: E045151
Rear Facing Display Mount Kit – Elo P/N: E835969 (Kit includes authorized E969524 Elo 2ft USB-C cable)
