Alfred AD-215-S for Android

Manufacturer:

Model Number: Alfred AD-215-S for Android

Maximize speed and convenience at the checkout with the AD-215-S self-checkout kiosk for a grab-and-go shopping experience. Ideal for use in high-volume retail environments such as convenience, drug, specialty, liquor, and hardware stores.High-speed scannerThe embedded 2D area imager enables fast scanning for higher throughput.Multiple Payment OptionsEasy and quick payment with support for debit and credit cards, contactless and mobile payments.Receipt & Coupon PrintingIntegrated and lockable 3-inch thermal printer for high-speed printing of receipts and coupons.Two bagging tablesTwo durable side tables provide convenient space for your items and bags.
Spec Sheet
Request a Quote

Alfred AD-215-S for Android Features

  • Kiosk solution with printing and payment capabilites
  • Available with 15.6″ or 21.5″ touch display (portrait or landscape)
  • Floor stand with two bagging tables
  • Embedded high-speed 2D area imager for barcode scanning
  • Available for Android 11, Windows 10/11 and Linux Ubuntu 22.04
  • Built-in, lockable 3-inch thermal printer
  • MSR, ADA keypad, payment terminal brackets, 5MP camera, RFID/NFC reader, LED status indicator (options)
  • Wi-Fi and BT connectivity (options)

Part Number(s):

  • AD-215-S-ANDROID

Accessories:

  • MSR
  • ADA keypad
  • payment terminal brackets
  • 2D barcode scanner
  • 5MP camera
  • RFID/NFC reader
  • LED status indicator
  • two bagging tables

View the full extent of our products

Download our free product catalog today!

Download Now

Detailed Specifications

  • Processors

    Rockchip RK3399

  • Display

    Size: 21.5”, Brightness: 220 nits, 400 nits (options), Resolution: 1920 x 1080 (or 1366 x 768), Aspect ratio: 16:9, Touch technology: PCAP touch

  • OS Support

    Android 9 and 11

  • Storage

    eMMC32GB + 1x Micro SD card slot (up to 128GB)

  • Memory

    LDDR4 4GB

  • I/O Ports

    2 x serial ports, RS-232 (RJ45), 0V/5V/12V selected in BIOS (COM1, COM2), 1 x Intel LAN (IEEE 802.3 10/100/1000 Mbps Ethernet, RJ45), 1 x RJ11 port with support for 2 cash drawers with 24V / 12V jumper setting, 1 x DC + 12V output, 1 x USB3.0 (OTG) + 5 x USB2.0, 1 x DC + 12V input, 1 x audio (1 x line-out), 1 x HDMI, 1 x Type-C (USB 3.1 Gen 1, 5Gbps)

  • Wireless

    2.4GHz/5GHz (IEEE 802.11a/b/g/n/ac), BT 4.2 (supports BLE)

  • Speakers

    1 x 3W speaker

  • Power

    AC-In 100~240V / DC-Out 12V, 90W

  • Spill & Dust Resistance

    IP54 (whole unit), IP65 (front panel)

  • Reliability

    System Operating Temperature: 0~40°C/ 32~104°F, System Humidity: 15% ~ 80%, Storage Temperature: -20~60°C / -4~140°F

  • Dimensions (W x H x D)

    Floor stand/landscape: 392 x 1424 x 401 mm / 15.4 x 56.1 x 15.8 in, Floor stand/portrait: 380 x 1511 x 401 mm / 15.0 x 59.5 x 15.8 in, Desk stand/landscape: 392 x 671 x 324 mm / 15.4 x 26.4 x 12.8 in, Desk stand/portrait: 290 x 752 x 324 mm / 11.4 x 29.6 x 12.8 in

  • Mounting

    Floor stand

  • Printer

    3-inch thermal printer

  • Barcode Scanner (Embedded)

    2D barcode scanner

  • Optional Peripherals

    Magnetic stripe reader (encrypted), EMV terminal brackets, Fingerprint reader, 5MP camera, RFID/NFC reader, ADA keypad, LED status indicator, Wheels kit: two wheels & one-handle

  • Warranty

    3-year standard warranty
